Our company official website:www.fitlifemac.com
Features & Usages:
- Feeding, punching, scrap collecting automatically.
- Very reliable as the controlling system adopts Siemens CPU 216 programmable logic controller (PLC).
- It is integration of Gas & Electrical, centralized control, so feeding length, speed and other parameters are easy to set.
- Manual setting of the feeding length from 20 to 9999mm by yourself.
The features are feeding accuracy, coating even, saving material, high accuracy, neat appearance, small size, easy to install, operate, maintain, little noise, as a result, it is the ideal equipment for aluminum containers & hardware products and so on.
Technical Parameter & Brief Specification:
- Max width of the material - 350-750mm (4 options)
- Max diameter of the material - 600m
- Feeding speed - 0-35m/min
- Feeding length - 20-9999mm
- Feeding accuracy - ± 0.3mm
- Production Capacity - From 35 to 80 units per minute
- Initial Machine Start Up - 30 - 50 Units per minute (2 Months)
- Voltage - 380V/ 220V
- Power - 1.0kw or 1.4kw (2 options)
- Dimension
- a. Feeding Machine (L x W x H) - 2000mm x 1550mm x 900mm (4 choices)
- b. Press, Die-Cut & Forming
Machine (L x W x H) - 1100mm x 1800mm x 2650mm
NOTE: Machine passed ISO9001: 2000 Certification.
Video presentation available upon receiving your reply
| Trademark: | Fineness/OEM |
|---|---|
| Standard: | SGS,FDA.TUV.ISO9001(+/2% for Thickness and Length) |
| Origin: | Zhangjiagang |
| Unit Price / Payment: | Fobshanghai |
| Productivity: | 10sets/week |
| Min order: | 1 sets |
| Packing: | Wooden case |
After-sales Service Provided:Engineers available to service machinery overseas
We have much experience in this line. We have exported to Italy, Greece, Russia, the Middle East, etc. we have passed ISO9001:2000, Haccp, AAA. Our aluminum foil related products have passed FDA, SGS, TUV. Our machines passed CE.With advanced equipments, superior quality administers and toping working team, we can offer our customers high quality products and the finest services. We are looking forward to establishing long-term business relations with clients
If you have another question, pls feel free to contact us as below:
Tel: 86- 0512-58793994
